Tips for setting up an EXIT swimming pool dome or canopy
02 juni 2023

Tips for setting up an EXIT frame pool dome or canopy

With an EXIT frame pool dome or canopy you get even more fun out of your above ground frame pool. When the sun’s out bright, the canopy offers protection against UV radiation. With a dome you can have fun in your very own indoor frame pool even when the weather isn’t that great. EXIT Toys has some convenient tips for setting up such a dome, so you can get the job done fast and start your swimming adventure!

Step 1: Preparation

Before you start it’s good to check whether you have all the parts. You can easily do this by means of the manual. Is there a part missing? Then first contact our customer service.



Below are a few more tips before the real work starts:

Set up the metal frame pool dome with two persons: an extra pair of hands will come in handy.

Place the bases for the straps underneath the legs of the frame pool before the frame pool is filled with water. Namely after filling the pool it’s very difficult to lift one of the legs. Place the bases at the front as well as at the back of the frame pool!

✔ While you continue setting up the dome you can start (partially)filling the above ground pool. With about 10 percent of frame pool water, the frame gets more stable, and the dome will be easier to attach.

Did you choose a dome and a canopy? Then first attach the impeller hinges of both products to each other. That way they’ll be much easier to work with.

Tips for setting up an EXIT swimming pool dome or canopy

Step 2: getting started with the setup of your dome

Have you arranged the tips we mentioned above? Good, now it’s time for some serious work.



Note: do you have a frame pool dome or canopy sized 400 x 200 or 540 x 250 cm? Then further in this blog we offer you some useful tips for setting up domes with these dimensions.



Attach the impeller hinges to the frame of the frame pool in the correct way (see manual).

→ The side with the fixed tube is the back of the hinge; this side cannot be opened. So think in advance at which side of the above ground frame pool you want the dome to open.

Connect the tubes to each other.

With the round domes you can easily click the tubes together.

The tubes for the rectangular domes have different lengths. Make sure you attach them in the right order.

In addition, with the rectangular domes it’s better to attach the last tube with a corner to the other side once the other tubes have already been passed through the tarpaulin or the canvas.

Lay the tarpaulin or canvas on the ground, for example on the grass or terrace and pass the tubes through the tarpaulin or the canvas. It is more convenient to do this together with someone else.

Push the tubes through the material instead of pulling them through. That way you’ll prevent the tubes from getting stuck in the tarpaulin.

→ The tubes should be on the inside of the dome. If rain remains on the material, the dome will not sag as quickly, and the material will be less likely to tear.

→ The round domes with a diameter of 427, 450 and 488 cm have a thicker tube, which you can use to open and close the dome. This should be placed at the front. You will find a larger connection for this in the impeller hinge.

Now lift the tarpaulin or canvas onto the frame of the frame pool and click the tubes in the tubes of the impeller hinge on both sides of the frame pool. It’s best to do this with two persons, especially when you have a larger size pool.

Do you have a frame pool dome of 400 x 200 or 540 x 250 cm?

The domes with frame pools sized 400 x 200 and 540 x 250 cm have a different impeller hinge, namely one with a pneumatic spring. Due to this, the dome can stay half open, without having to attach it to the frame with straps.
When you’re not using the pool, you can firmly attach the closed dome to the pool with the added elastic bands. That way you also make sure no dirt can end up in the frame pool.



Good to know: these domes are only suitable for the rectangular frame swimming poles sized 400 x 200 and 540 x 250 cm of EXIT Toys!



Tips to take into account:

The manual states that you must attach the pneumatic spring to a tube of the impeller hinge by means of a screw. This screw is already inside the tube so you will not find it in the bag with the added separate screws.

Attach the impeller hinges to the frame pool frame in the correct way (see manual). You can see how the dome opens on the sticker on the inside of the hinge.

Attach the tubes to each other and pass them through the tarpaulin or canvas (see Step 2).
Now lay the tarpaulin or canvas on the frame pool and click the tubes in the hinges. Especially with domes of these dimensions we recommend doing this together with someone else. That will make this job much easier.

That’s it, the work is done! Namely you can skip Step 3: these tips are meant for all other EXIT domes. You can now go and enjoy your EXIT frame pool with dome and/or canopy!

Tips for setting up an EXIT swimming pool dome or canopy

Step 3: the final steps...

The end is near. All that’s left now is dotting the i’s and crossing the t’s and then you can go and enjoy the benefits of your EXIT dome or canopy.



Attach the straps of the dome or the canopy to the frame of the frame pool.

When you are not using the frame pool, you can attach the dome to the pool with these straps. That way you also prevent dirt from ending up in the water and of course you will benefit from a natural heating of the water.

When the dome is open, then neatly fold the tarpaulin or canvas and secure it to the back of the pool with the straps. Make sure the material is dry, to prevent mould from forming on in.



Now your frame pool with dome and/or canopy is completely ready for summer. Are you having a less summery day or are you looking for a refreshing spot away from the bright sun and in the shade? With an EXIT dome or canopy you will get maximum fun out of the swimming season!

Would you like to find out more? Call, email, or chat with us!

Do you have any questions about setting up an EXIT dome or canopy? Or could you use some extra help? Let us know, our customer service is here for you! Feel free to contact us through the chat, call  +31 314 - 796 020  or send an email to info@exittoys.com. We are happy to help so you can quickly enjoy your swimming adventure!

Tips for setting up an EXIT swimming pool dome or canopy
Written by: Geke
